Capture and Remove Toxic Airborne Chemicals, Odors, Dust, & Other Fine Indoor Particles with A Top-Rated Commercial Grade Air Cleaner. Here We Offer One of the Best Combination Dust Collector, Fume Extractor and Smoke Eater Machines with High-Quality Industrial HEPA Filter & Activated Carbon Scrubber System for Laser Engraving, Welding, and Soldering Shops, Trade Schools, Construction Job Sites & Home Workshops All at A Discount Price with Free Shipping!

FEATURES AND BENEFITS

Top Filter Access Panel and Intake – Panel slides with use of handle and lifts without difficulty to access filters for maintenance.

Metal Mesh Prefilter on Intake – provides heavy duty large particulate filtering and protects the interior filters, extending ultrafine and VOC filtering performance.

Adaptable Fresh Air Intake Port – allows for new external air to be filtered and introduced to the environment. Can be used to create a positively pressurized “safe-room” environment.

Steel Construction with Baked Thermoset Powder Finish – tough wear and tear resistant housing that doesn’t off-gas chemicals, true to the integrity of providing clean air!

Interior Filters – final 3 stages of filtration is contained and protected within a durable steel cabinet.

Perfect Seal Filter Configuration – Easy-Twist HEPA locks into place to ensure the filter is completely sealed in the unit and no polluted air leaks.

Perfect Seal 3 Stage Filtration – capture large particulate and VOCs with the first stage foam prefilter, harmful and irritating particulate are trapped with the second stage HEPA filter that locks in place and chemical/gas pollution are adsorbed by the third stage carbon VOC filter.

4 Easy-Twist HEPA Cartridges – Filters are convenient to access and change with just a twist of the main HEPA Cartridge.

Standard Third Stage VOC Canisters – 3 x 1550 g of granulated carbon provide vital capture of chemical and gas pollution.

Variable Speed Control – change the system rate of air flow to suit capture needs to the level of contaminants in the environment.

High Efficiency AC Backward Curved Motor – High performance airflow at a low running cost, minimal drain on electricity resources with years of continuous performance.

Options:

Ultra VOC Filter Upgrade – replaces up to 3 HEPA Cartridges with 9475 g canisters of granulated carbon for cases requiring extreme chemical and gas pollution capture. Customized treated Carbon fills available upon request.

Collared Intake Panel – allows for rigid or flexible ducting connection to configure targeted source capture of pollutants.

WHAT’S IN THE BOX

1 – IS5000 IS 5000 HEPA Air Filtration System
1 – IS5000 Owner’s Manual

TECHNICAL SPECIFICATIONS

ITEM:  19-A-1KME-01

Maximum Recommended Area Size: 135,000 ft3

Filter Life:             Prefilter – 12 months

HEPA Filter – 3 to 5 years

VOC Carbon Canister – 6 months

Filter Configuration: Cylindrical Perfect Seal 3-Stage Cartridge (13” Diameter x 16” Height)

Stage One: 1/8” Foam Prefilter x3

Stage Two: 100 sq. ft. Pleated Easy Twist HEPA Cartridge x3

Optional Stage Two: Granulated Carbon pellets incased in steel mesh canister (9475 g = 10,422,500 m2adsorption surface area) per canister x3

Stage Three: Granulated Carbon pellets incased in steel mesh canister (1550 g = 1,705,000 m2 adsorption surface area) per canister x3

Airflow (nominal):  2250 CFM

Power Consumption:  635 W

Dimensions:  32” W x 27”L x 43.5”H

Weight:  165 lbs.

dBA Rating @ 6’:

Control:  Manual Toggle – ON/OFF

Construction:  24 gauge steel housing, durable baked thermoset powder finish

Colour:  Meteorite

Intake:  10” Round with protective metal mesh x2

Outflow:  Bottom located, 10” x 14” with protective metal mesh

Motor:  Backward curved impeller/fan

Voltage:  115 volt*

Cord/Plug:  12 foot detachable IEC cord with North American Type K Plug (3 pin grounded)

*available in most commercial voltages with standard plugs.

***LEAD TIME 6-8 WEEKS FROM DATE OF ORDER***
